Electrical Medical and Chemical Calibration Group (EMC), Reference Calibration Laboratory Center (RCLC)

The fully assembled automatic meniscus leveling device was developed in this research, which aims to create both an instrument and software for automatic meniscus (Meniscus) adjustment. The system consists of a control unit and performance testing. The control unit includes electrical components for pipette movement, a motorized suction–dispensing system, a digital microscope camera, and the DSS Pipette Calibration program, which controls all operations in real time.

Test results show that the system can measure volume accurately, reduce human error, and enable operators to correctly adjust the meniscus level without prolonged eye strain.

---

✨ 1. Significant Products:

Automated Meniscus Leveling System for Volumetric Glassware Calibration

The objective is to reduce the measurement error caused by visual reading of the meniscus (human error) and increase the accuracy of calibrating instruments such as pipettes.

• Definition and Scope: It is an instrument that utilizes motor-driven technology and real-time image processing to precisely adjust the liquid meniscus level inside a pipette without the need for human sight.
• Key Features:
  • Automatic meniscus leveling using a motorized system.
  • Real-time display of the meniscus level via a digital camera.
  • Controlled through software directly connected to the hardware.
• Application: Suitable for both government and private volumetric glassware calibration laboratories that require high accuracy and reduced workload for operators.

---

🏢 2. Responsibilities of Group:

The primary roles are to provide calibration services for volume measuring instruments to both government and private sectors, as well as to conduct research and development of technology to enhance the laboratory’s capability to meet international standards and build confidence in measurement results.

• Conduct research to develop new instruments/innovations.
• Provide high-accuracy calibration services for measuring instruments.
• Provide technical support and training to other organizations.
• Support the preparation of standards and academic documents.

Chemical Calibration Laboratory

Chemical calibration laboratory specializes in electrochemical measurement instruments, particularly pH and conductivity meters. We are committed to continuously expanding our services to meet emerging needs across new scientific and industrial fields, while also enhancing the measurement techniques of our existing services to ensure greater accuracy and reliability.

Providing electrochemical calibration services such as pH meters and electrolytic conductivity meters.

Electrical and Frequency Calibration Laboratory

The main responsibilities are providing calibration services for electrical and frequency measuring instruments to both government and private sectors, as well as conducting research and development of technology to elevate the laboratory’s potential to meet international standards and foster confidence in measurement results.

• Conducting research to develop new instruments/innovations.
• Providing high-accuracy measurement instrument calibration services.
• Offering technical support and training to other organizations.

– multi-product calibrator Fluke 5520A
– DC voltage referent standard Fluke 732C ร่วมกับ DMM Fluke 8508A
DC voltage reference standard can be used with multiplier and switcher, can provide high resolution DC voltage calibration directly at 0.1 V, 1 V, 10 V and other values when using multiplier.

Medical instruments Calibration Laboratory

The primary roles are to provide calibration services for medical measuring instruments to both government and private sectors, as well as to conduct research and development of technology to enhance the laboratory’s capability to meet international standards and build confidence in measurement results.

• Conduct research to develop new instruments/innovations.
• Provide high-accuracy calibration services for measuring instruments.
• Support the preparation of standards and academic documents.

– Non-invasive sphygmomanometers Based on SMM 02-1
– Static pressure 0 kPa to 34 kPa (0.42 kPa)
– Pulse rate 30 BPM to 180 BPM (2.0 BPM)

Vibration Calibration Laboratory

---

🎯 3. Scope of Research Field:

Development of High-Precision Measuring Instruments, Control Software, and Automated Calibration Systems
Including the application of image processing technology and embedded systems to support efficient calibration processes.

• Main Field: Metrology (Volume Measurement)
• Core Techniques: Automatic Control Systems, Image Processing, Embedded Systems
• Objective: To enhance measurement accuracy, reduce human error, and elevate laboratory performance to meet international standards.

---

🧪 4. Related Testing/Calibration:

• Burette : Based on ISO 4787 : 2021
• Piston pipette : Based on ISO 8655-6 : 2022
• Graduated pipette : Based on ISO 4787 : 2021
• Cylinder : Based on ISO 4787 : 2021
• Volumetric pipette : Based on ISO 4787 : 2021
• Volumetric flask : Based on ISO 4787 : 2021

---

🥼 5. Testing Services:

---

🔬 6. Key Scientific Instruments/Techniques:

• High-precision balance
• Digital microscope camera

---

🏆 7. Outstanding Achievements/Awards and Honors:

–

---

📄 8. Reference publications/Journal:

Development of automatic meniscus adjustment instrument

---
